The complete pipeline¶

Level: Foundation → Architect · Time: 60 minutes

An LLM release is the output of a versioned supply chain. You should be able to point from a generated token back to the serving configuration, checkpoint, training run, batch, tokenized record, processed document, and source policy that made it possible.

The lifecycle at one glance¶

flowchart TB
    subgraph D[1. Data system]
      D1[Source inventory] --> D2[Acquire and snapshot]
      D2 --> D3[Parse and normalize]
      D3 --> D4[Filter, deduplicate, redact]
      D4 --> D5[Decontaminate and classify]
      D5 --> D6[Mix, shard, sample]
    end
    subgraph R[2. Representation]
      R1[Train tokenizer] --> R2[Freeze artifact]
      R2 --> R3[Encode and pack]
    end
    subgraph P[3. Pretraining]
      P1[Initialize model] --> P2[Forward and loss]
      P2 --> P3[Backward and optimize]
      P3 --> P4[Checkpoint and evaluate]
      P4 --> P2
    end
    subgraph T[4. Behavior shaping]
      T1[Supervised instruction data] --> T2[SFT checkpoint]
      T2 --> T3[Preferences, rewards, or verifiers]
      T3 --> T4[Safety and capability evals]
    end
    subgraph S[5. Serving]
      S1[Convert, shard, or quantize] --> S2[Inference runtime]
      S2 --> S3[Batch, schedule, cache]
      S3 --> S4[API and observability]
    end
    subgraph A[6. Application]
      A1[Messages and templates] --> A2[Retrieval and tools]
      A2 --> A3[Agent loop or direct response]
      A3 --> A4[Product evals and feedback]
    end
    D6 --> R1
    R3 --> P1
    P4 --> T1
    T4 --> S1
    S4 --> A1
    A4 -. governed improvement signal .-> D1

The arrows are contracts. Most costly failures occur when one stage silently violates the next stage's assumptions.

Stage 1: source and curate¶

The durable artifact is not “a pile of JSON.” It is a manifest connecting each record to source, snapshot, transformations, policy, and version. A robust pipeline keeps raw acquisition separate from derived training shards so a policy change can be replayed.

Key outputs:

• source register and terms review;
• immutable or content-addressed raw snapshot references;
• parser and language/content classifiers;
• exact and near-duplicate clusters;
• sensitive-data and opt-out/takedown actions;
• evaluation decontamination decisions;
• mixture weights and sampling unit;
• quality statistics by slice, not only global totals.

Stage 2: create the token protocol¶

Train candidate tokenizers on a documented sample, measure representation across the target mixture, then freeze vocabulary, merges/scores, normalization, and special IDs. Encode, concatenate, and pack documents with explicit boundary tokens and loss masks.

Packing can put several documents into one sequence. Decide whether attention may cross document boundaries and whether separator tokens contribute to loss. These are model-semantic choices, not storage details.

Stage 3: pretrain¶

For decoder-only next-token prediction, each packed token sequence supplies shifted targets. A distributed run repeats:

load -> forward -> loss -> backward -> reduce/partition gradients
     -> clip -> optimizer -> schedule -> metrics -> checkpoint

The exact global token batch is part of the optimization configuration. Parallelism changes where tensors live and communicate; it should preserve the intended model update within accepted numeric differences.

Stage 4: shape behavior¶

Pretraining teaches broad sequence completion. Instruction data teaches an interaction format and desired responses. Preference objectives or reinforcement learning change relative behavior under chosen feedback. Safety work spans data, objectives, red teaming, policies, serving controls, and incident response; it is not one final filter.

Keep a checkpoint graph rather than overwriting “the model”:

flowchart LR
    B[Base] --> S[SFT]
    S --> D[DPO run]
    S --> R[RL run]
    R --> LC[Long-context variant]
    D --> Q[Quantized deployment]
    R --> Q2[Quantized deployment]

Each edge should name its input data, code revision, configuration, and evaluations.

Stage 5: turn weights into a service¶

Checkpoint conversion and quantization can change numerical behavior. Serving must manage:

• model shards and tensor/expert placement;
• request admission and fairness;
• prefill versus decode scheduling;
• KV-cache allocation and eviction;
• continuous batching;
• sampling and structured output;
• timeouts, cancellation, and backpressure;
• latency, throughput, memory, errors, and quality canaries.

Optimize time to first token, inter-token latency, end-to-end latency, and tokens per second separately. One number hides trade-offs.

Stage 6: build the application contract¶

Applications decide what the model actually sees. Serialize trusted instructions, user data, retrieved documents, tool schemas, and observations with explicit precedence and boundaries. Validate model-proposed tool arguments before execution. Preserve provenance between generated claims and retrieved evidence where the product promises citations.

A traceability record¶

release: example-1b-instruct-v1
base_checkpoint: sha256:...
tokenizer: sha256:...
pretraining_run:
  code_commit: abc123
  config: configs/example-1b.yaml
  data_manifest: sha256:...
post_training:
  sft_manifest: sha256:...
  preference_manifest: sha256:...
evaluation:
  harness_commit: def456
  raw_results: evals/example-1b-v1/
serving:
  runtime_image: sha256:...
  quantization_recipe: none

This is illustrative. A real release also needs licenses, risk analysis, people and approval records, known limitations, hardware/software environment, and incident/takedown routes.

System-level failure exercise¶

For each symptom, name at least three possible stages:

• multilingual requests cost twice as many tokens;
• a benchmark jumps after a corpus refresh;
• training loss spikes after resuming;
• one MoE device is saturated while others idle;
• citations look plausible but do not support answers;
• the same checkpoint behaves differently in two deployments.

The point is not to guess. It is to instrument the boundaries so the responsible stage can be identified.
